TB V2 HEAD VALVE KIT KLX - TBW0886

This kit is designed and manufactured by TB Parts who specialise in pit bike performance parts in USA.

FITS:
TB V2  KLX/YX160 TB CASTING Style Heads (Not HONDA/IMPORT)

SPEC:
Intake Valve Length = 74.90mm
Intake Valve Head O.D = 30.00mm
Intake Valve Stem O.D = 5.00mm
Exhaust Valve Length = 73.50mm
Exhaust Valve Head O.D = 24.50mm
Exhaust Valve Stem O.D = 5.00mm
Material = EV8 Stainless Steel
Outer Spring O.D = 23.50mm
Outer Spring I.D = 16.70mm
Outer Spring Length = 36.70mm
Inner Spring O.D = 15.50mm
Inner Spring I.D = 12.00mm
Inner Spring Length = 32.20mm
Valve Stem Oil Seal = 5.00mm
Valve Base Shim O.D = 22.95mm
Valve Base Shim I.D = 16.70mm
Valve Base Shim Thickness = 1.00mm
TB PART KIT NUMBER = TBW0886

Item Includes:
1x Intake Valve
1x Exhaust Valve
2x Valve Springs
2x Inner Valve Springs
4x Valve Cotters
2x Valve Base Shims
2x Valve Stem Oil Seals

PLEASE NOTE
Theses only fit TB KLX STYLE Heads
